您的位置：產品中心
產品中心Products center
VHS NEMA系列-TEFC
VHS NEMA Motors-TEFC
高級功能包括：
Premium features include:
三相IV極60Hz
Three-phase, IV pole, 60Hz
電壓：208-230-460Hz，575V
Voltage: 208-230-460Hz, 575V
鑄鐵工藝
Cast iron construction
高轉速、高推力設計（雙疊推力軸承標準）
Hi-torque, Hi-thrust design (double stack capable)
精密平衡
Precision balancing
104 F環境溫度
104° F ambient temperature
“F”類絕緣
Class ‘F’ insulation
F級溫度上升@ 1.15
Class ‘F’ Temperature Rise @ 1.15
超大的角接觸軸承和滾珠軸承
Oversized angular contact bearing and ball bearing
大型油藏（324TP-5809TP）
Large oil reservoir (324TP-5809TP)
雙VPI
Double VPI treatment
空間加熱器
Space heaters
鍛造球型非反向棘輪
Forged ball-type non-reverse ratchet
6或12根啟動導線
6 & 12 leads for starting capability
熱敏電阻PTC
Thermistors PTC style
產品選項：
Product options:
備用聯軸器
Alternate couplings
備用機座
Alternate bases
高級效率電機
Premium efficiency motors
垂直實心軸(根據訂單)
Vertical solid shaft (upon order)
洛渤電機全封閉風扇冷卻(TEFC)立式泵電機正迅速成為業界最知名的品牌。我們強大的電機執行在最艱苦和極端的條件下，并從最高質量的材料建成。
RE motors Totally Enclosed Fan Cooled (TEFC) Vertical Pump Motors are rapidly becoming the most recognized brand in the industry. Our robust motors perform under the most strenuous and extreme conditions and are built from the highest quality materials.
我們堅固的 TEFC 逆變電動機設計，以響應一些最苛刻的應用，如水和廢水，農業，市政當局，采礦，紙漿和造紙廠，以及鉆井的權力和強度。
Our tough TEFC inverter-duty motors are engineered to respond with power and strength in some of the most demanding applications, such as water and wastewater, agriculture, municipalities, mining, pulp and paper mills, and well drilling.
面對環境
Facing the environment
洛渤電機中的每個組件都在超越您的期望。例如,絕緣系統在承受各種環境條件、熱沖擊和電壓應力。繞組采用雙真空壓力浸漬(VPI)和不吸水的環氧清漆,以提供******程度的保護。熱帶清漆適用于沿海地區、采礦應用以及高濕度或有害顆粒場所使用的電機。
Each component in the RE motor is exceeding your expectations. For example, insulation systems are subjected to various environmental conditions, thermal shocks, and voltage stresses. The winding uses double vacuum pressure impregnated (VPI) and non-suction epoxy varnish to provide maximum protection. Tropical varnish is suitable for motors used in coastal areas, mining applications, and in places with high humidity or harmful particles.
服務行業廣泛
Service industry is extensive
我們堅固耐用的TEFC變頻電機設計用于在一些要求最苛刻的應用中提供強大的動力和強度,例如水和廢水處理、農業、市政、采礦、紙漿和造紙廠以及鉆井。
Our rugged TEFC inverter motors are designed to provide strong power and strength in some of the most demanding applications, such as water and wastewater treatment, agriculture, municipal, mining, pulp and paper mills, and drilling.
